BRAND：Anritsu
Features:
With LED backlight display, larger size (7 inches), higher resolution (800 * 480)
The longer battery time (maximum 12 hours)
Wider operating temperature range (-10 to 50 DEG C)
More light, weighing only 2.6 kg (5.7 lb)
Test preparation time less than 15 seconds
Battery operating time of 8 hours
According to the test pattern in different occasions, such as the standard,engineering, fault location model
Standard light source and optical power meter
High resolution 5cm
The 0.8 metres event blind
39/37.5dB dynamic range
Internal memory more than 1000 curves, external USB storage up to 30000 curves
Provide long-term use in the harsh environments to ensure strong shapedesign of seal
Online optical fiber inspection mechanism can protect the instrument andequipment effectively
Support generic Telcordia SR-4731 format (Second Edition)
Free and easy software upgrade
Description:
Technicians maintaining diverse systems are forced to carry a large variety of test equipment on-site, including OTDRs, Light Sources, Optical Power Meters, Visible Light Sources, etc., as well as a notebook computer for evaluating the FTTx QoS. On the other hand, fiber construction requires measuring instruments with different functions and performance.In addition, core and backbone networks utilize long fibers while optical access networks use short fibers, both requiring different types of measuring instruments with different performance.But now Anritsu's new line of MT9083 ACCESS Master OTDRs solves all these problems by providing all the measurement functions and performance required for optical fiber construction and maintenance in a compact, lightweight, all-in-one unit that eliminates the burden of carrying many different test sets and instruments on-site.
