BRAVD：DVP
Description:
The DVP 322 Optical Time Domain Reflection is a dexterous, stable, durable optimized OTDR for broadcast and TV network, engineering installation of telecommunication network and maintenance testing.
Features:
Fast testing function, One-key operation, easy to operate
Smart portable OTDR, 4.3 inch TFT LCD display
Firm, durable, shock-proof, moisture-proof, (VFL)Visual fault location function
Built-in lithium rechargeable battery, more than 8 hours working hours
Support USB and RJ45 interface, more convenient to manage files, Toolbox PC simulation software
Specifications:
|
Wavelength(nm) |
Dynamic Range(dB) |
Event Dead Zone(m) |
Attenuation Dead Zone (m) |
|
1310±20/1550±20 |
34/32 |
<3m |
<25m |
General Parameters:
|
Distance range(Km): |
5m~160km (Dead Zone,100m,300m,1km,3km,10km,30km, 5m~160km (Dead Zone,100m,300m,1km,3km,10km,30km, |
|
Pulse width(ns): |
5ns-10ns |
|
Measurement time: |
user-defined(smart link) |
|
Distance accuracy(m): |
±(0.5m ±0.001%range + sampling resolution) |
|
Attenuation accuracy: |
±0.05dB/dB |
|
Loss limit(dB): |
0.01dB |
|
Loss resolution(dB): |
0.001dB |
|
Sampling resolution(m): |
0.1m |
|
Sampling points: |
128000 |
|
Data storage: |
3000 item |
Other Indicators:
|
LCD type: |
4.3 inch TFT colorized LCD |
|
Laser adapter: |
FC/PC SC/PC |
|
Interface: |
USB,RJ45 |
|
Battery: |
built-in rechargeable Li-ion battery charging time <4 hours working |
|
Power: |
AC/DC adapter input AC90-240V 鹵10% output DC12V |
|
Operating temperature: |
0℃ ~40℃ |
|
storage temperature: |
-10℃ ~50℃ |
|
relative humidity: |
<80% |
|
weight: |
<1.0Kg |
|
dimensions(mm): |
200*126*62mm |
