BRAND：NOYES
Specifications
Hand-held, rugged, lightweight
Dual wavelengths from a single port
Dual or single Wave ID, CW, Tone Output
Dual Wavelength LED Source
NOYES OLS1-Dual is a hand-held, rugged LED light source designed for performing insertion loss measurements on multimode fiber optic links when used with an optical power meter. The LED output is stabilized to ensure accurate test results per current TIA/EIA requirements.
Multimode Output Port; emits 850/1300 nm LED output at CW, WaveID, or dual wavelength WaveID.
Faster Test Times with WaveID – In WaveID mode, the NOYES OLS4 encodes each wavelength with a unique WaveID code. When used with a NOYES power meter, the pair can send and receive two wavelengths each test – doubling testing efficiency – reducing test time!
Flexible Output Connector Adapter Design
The OLS1-Dual output ports are equipped with UCI based removable adapters to allow the output connectors to be inspected and cleaned, while allowing field change of output style between FC, SC, ST, & LC connector adapters.
50 and 62.5 μm fiber mandrels Included
Mandrels condition test cable for use in certifying both 50 and 62.5 μm fiber links for current and planned high bit rate applications including Gigabit Ethernet and 10 Gigabit Ethernet. Mandrels apply to launch jumpers is seconds without tools and ensure loss measurements comply with TIA/EIA-568-B standard.
The OLS1-Dual is fully N.I.S.T. traceable.
Key Specifications
· OLS1-Dual Optical Port Wavelengths: 850 and 1300 nm
· Output Power: -20 dBm, 62.5 μm multimode
· Output connector: FC, SC, ST, LC switchable (One style supplied with unit, order others separately)
· Battery: 2 x AA Alkaline, optional AC adapter
Applications:
· Certify 50 or 62.5μm fiber links to TIA/EIA Standards
· Certify Multimode fiber links for Gigabit Ethernet (GBE)
· Test Ethernet, Token Ring, and FDDI fiber networks
· Use 1300 nm port to test up to 10 km single-mode fiber links
