BRAND：EXFO
Description
EXFO FTB-1-720 OTDR is based on multi-level and many medium test and design of the super modular platform type. FTB-1-720 contains two field replaceable module slot, can test physical layer, the transport layer data and the layer.
Features : Access network testing
LAN/WAN characterization
Dynamic range of up to 35 dB
Event dead zone as low as 0.8 meter
Combined singlemode/multimode wavelengths (12CD-23B model)
Integrated tool: combines a visual fault locator, inspection probe, broadband power meter and a CW source mode
Controlled launch conditions fo more accurate loss measurements
Live fiber testing at 1625 nm
Parameter
|
display |
touch screen,colour,800脳480TFT,178mm(7 inch) |
|
connector |
Two USB2.0 port |
|
storage
|
8GB internal memory(flash memory) |
|
battery |
Replaceable lithium ion battery |
|
power supply |
AC/DC adapter, input 100 ~ 240 VAC, 50 ~ 60 Hz, 2 A maximum, 24 VDC output, 90 W |
|
main engine |
Intel Atomprocessor |
SPECIFICATIONS
|
GENERAL SPECIFICATIONS |
|
|
Temperature |
|
|
Operating |
-5 °C to 50°C |
|
Storage |
-40 °C to 70 °C |
|
Relative humidity |
0 % to 95 % non-condensing |
|
Size (H x W x D) |
322 mm x 197 mm x 109 mm (12 11/16 in x 7 3/4 in x 4 5/16 in) |
|
Weight |
2.5 kg (5.4 lb) |
|
Vibration |
< 1.5 g at 10 Hz to 500 Hz (on three main axes) |
|
Mechanical shock |
< 760 mm on six sides and eight main edges (according to GR-196-CORE) |
Modules:
|
FTB-720-000-04B |
FTB-720-000-04B-XX, SM OTDR Module, Filtered 1625 nm, 34 dB (9/125 nm) for live fiber testing |
|
FTB-720-023B-04B |
FTB-720-023B-04-XX, SM OTDR Module Port 1 : 1310/1550 nm, 36/34 dB (9/125 nm) Port 2 : Filtered 1625 nm, 34 dB (9/125 nm) for live fiber testing |
|
FTB-720-023B |
FTB-720-023B-XX, SM OTDR Module, 1310/1550 nm, 36/34 dB (9/125 nm) |
|
FTB-720-12CD |
FTB-720-12CD-XX, MM OTDR Module, 850/1300 nm, 27/26 dB (50/125 & 62.5/125 nm) |
|
FTB-720-12CD-23B |
FTB-720-12CD-23B-XX-XX, MM/SM OTDR Module, 850/1300/1310/1550 nm, 27/26/36/34 dB (MM: 50/125 & 62.5/125 nm - SM: 9/125 nm) |
