BRAND： JDSU
MTS-4000 Multiple Services Test Platform Modular handheld test solution for all-in-one Access/FTTx network and triple-play services installation and maintenance.
Description:
All-in-one Access/FTTx/Triple-Play Services Test Set
The MTS-4000 is a small, compact and handheld test platform designed for all phases of the
network lifecycle, from the installation to the maintenance of Access/FTTx networks and
triple-play services. Modular in design, the MTS-4000 offers field service
technicians the highest performance and superior levels of scalability and upgradeability.
Highlights:
Large 7-inch indoor/outdoor color display
Cost-effective, compact and handheld platform
Multi-layer network solution from physical to services layer
Highly scalable with up to 2 field-replaceable modules
Connection checker with VFL, power meter and video inspection scope options
Flexible connectivity for fast data transfer: 2xUSB 2.0, up to 1 Gb/s Ethernet
Features:
Lightweight platform: only 1.4kg/3 lbs
Intuitive graphical user interface with touchscreen option
Extended battery life using smart Lithium ion cell
Scripting capability for automation, simplification and automatic data reporting
Easy Internet access via installed web browser
Remote control access allowing remote assistance from any expert user
ntegration of basic applications such as HTML and PDF reader
Comprehensive suite of PC software tools for post-processing of test results with FiberTrace (OFS-100) andFiberCable (OFS-200)
Applications:
Fiber test applications include OTDR, PON meter, video inspection scope,
laser source/power meter, and VFL
Copper test applicationsinclude volt/ohm meter, time domain reflectometer (TDR),
resistive fault locator, and wideband tones/spectal analysis to 30 MHz
Triple-play service testing/IPTV and VoIP measurements from DSL access interfaces
or standard Ethernet port
VDSL and ADSL testingusing Infineon Technologies chipset and licensed option for
Dr. DSL? diagnostic solutions from Aware, Inc.
Specifications:
|
General Technical Specifications (Typical at 25 °C) |
|
|
Display |
TFT color, 7-in, LCD 800 x 480, high visibility for outdoor |
|
Weight |
0.35 kg (0.77 lb) |
|
Dimensions(W x H x D) |
128 x 134 x 40 mm (5.04 x 5.28 x 1.58 in) |
|
Storage |
Bellcore/Telcordia-compatible (Version 1.1 and Version 2.0) |
|
Optical interfaces |
|
|
Applicable fiber |
SMF 9/125 mm |
|
Interchangeable optical connectors |
FC, SC, DIN, LC (PC or APC) and ST (PC) |
